    Ductile Iron Grooved Butterfly Valve , Card Slot Worm Gear Butterfly Valve

    Ask Lasest Price
    Brand Name : Y
    Model Number : D381X-16Q
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 10000 pcs per year
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    Ductile Iron Grooved Butterfly Valve , Card Slot Worm Gear Butterfly Valve

    Fire Card Slot Worm Gear Butterfly Valve 1.6 Mpa Fire Protection Valves


    Introduction


    The grooved butterfly valve adopts worm gear and worm drive, and then the cam rotates to press or release the contact on the signal device according to the predetermined position, and the corresponding "on" and "off" electrical signals are output to display the opening and closing status of the butterfly valve. Grooved butterfly valves are divided into handle grooved butterfly valves and turbine grooved butterfly valves.


    Dimension


    DNLL1L2фф1Hc
    65103±214.59.571.676178200
    80103±214.59.584.689202245
    100118±2169.5109.6114222280
    125128±2169.5135.6140233280
    150150±2169.5160.6165257280
    1200188±21913214219295320

    Part name and material

    BodyDuctile Iron
    DiscDuctile Iron /ss
    Stemss
    Handlesteel
    seatEPDM / NBR

    Feature


    Nominal pressure1.6mpa
    Shell test2.4 mpa (water)
    Seal Test0.6mpa (gas)
    Seal Test1.76 mpa (water)
    Suitable temperature≤80℃
    Suitable mediumwater
    butterfly plate corner90°
