    Russia Standard Flanged Globe Valve 1.0/2.5/4.0 Mpa Rising Stem WCB

    Ask Lasest Price
    Brand Name : Y
    Model Number : J41H
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 10000 pcs per year
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    Russia Standard Flanged Globe Valve 1.0/2.5/4.0 Mpa Rising Stem WCB

    Russia Standard Medium Steam/ Water Pressure 1.0/2.5/4.0 Mpa Flanged Globe Valve


    Introduction


    The opening and closing part of cast steel stop valve is a cylindrical disc, the sealing surface is flat or conical, and the disc moves in a straight line along the center line of the fluid. The national standard stop valve is only applicable to full opening and full closing. It is generally not used to adjust the flow. It is allowed to adjust and throttle when customized. Cut off or connect the pipeline medium on the pipelines under various working conditions such as petroleum, chemical industry, pharmaceutical, chemical fertilizer and electric power industries with nominal pressure of 1.6mpa-16.0mpa and working temperature of - 29 ~ 550 ℃. The driving modes include manual, gear transmission, electric, pneumatic, etc.


    Test Pressure


    TypeNominal Pressure (MPa)Testing PressureSuitable Temperature (C)Suitable Medium
    Strength(Watcr)(MPa)Enclosc(Water)(MPa)
    J41H-16C1.62.41.8<425Waiter. Vapour, Oil
    J41H-252.53.82.8
    J41H-404.06.154.51
    J41H-646.49.757.15

    Dimensions

    Type 型号Nominal DN1520253240506580100125150200250300
    J41H-16CMeasurctnent(mm)L130150160180200230290310350400480600622698
    D95105115140150165185200220250285335405460
    D1657585100110125145160180210240295355410
    Zxфd4Xф144Xф144Xф144Xф 184X ф184Xф184Xф188xф188xф188xф188xф2212x ф2312x ф2512x ф25
    J41H-16CWeight (kg)4.65.66.810.2514.618.428.53444.667.690.5157.5225351

    Type 型号Nominal DN1520253240506580100125150200250300
    J41/941^-25Measurctnent(mm)L130150160180200230290310350400480600622711
    D95105115135145160180195230270300360425485
    D1657585100110125145160190220250310370430
    Zxфd4Xф144Xф144Xф144Xф 184X ф184Xф188Xф188xф188xф238xф258xф2512x ф2612x ф3016x ф30
    j41h-25Weight (kg)4.65.66.9210.415.118.427.53454.7583112.5168.5226.5391
