    200X Pressure Reducing Water Conservancy Valve Ductile Iron Anti Erosion

    Ask Lasest Price
    Brand Name : Y
    Model Number : 200X-16Q
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 10000 pcs per year
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    200X Pressure Reducing Water Conservancy Valve Ductile Iron Anti Erosion

    200X Pressure Reducing Valve Ductile Iron Flange End Water Conservancy Valve


    Usage

    The product is the ideal product for the life water, fire water and industrial water supply system.


    Introduction


    200X pressure reducing valve is a valve used in the parallel water supply system of fire water and domestic water to adjust the water supply direction.

    In case of fire, fire fighting is in urgent need of a large amount of water, and domestic water shall be cut off immediately to ensure sufficient fire water; When the pressure of fire water is reduced, the valve will automatically open and be normally open to restore domestic water supply. The valve makes it unnecessary for the system to set up a separate fire water supply network, which greatly saves the construction cost and water consumption. The valve has the advantages of high control sensitivity, safety and reliability, simple commissioning and long service life


    Main parts and materials


    BodyDuctile Iron
    BonnetDuctile Iron
    Stem2Cr13
    Pressure reducing valveBrass/304
    Needle ValveBrass /304
    Ball ValveBrass /304

    Dimension


    DN

    L

    ф

    ф1

    ф2

    N-ф3

    50

    203

    99

    125

    165

    4-ф19

    65

    216

    118

    145

    185

    4-ф19

    80

    241

    132

    160

    200

    8-ф19

    100

    292

    156

    180

    220

    8-ф19

    125

    330

    184

    210

    250

    8-ф19

    150

    356

    211

    240

    285

    8-ф23

    200

    458

    266

    295

    340

    12-ф23

    250

    530

    319

    355

    405

    12-ф28


    200X Pressure Reducing Water Conservancy Valve Ductile Iron Anti Erosion200X Pressure Reducing Water Conservancy Valve Ductile Iron Anti Erosion200X Pressure Reducing Water Conservancy Valve Ductile Iron Anti Erosion
